Design a Parking Lot System

Problem Statement

Design a parking lot system that can:

• Handle multiple floors
• Support different vehicle types (Car, Motorcycle, Truck)
• Track available spots
• Calculate parking fees
• Process payments

Requirements

Functional Requirements

1. Multiple entry and exit points
2. Different parking spot sizes (Compact, Large, Handicapped)
3. Real-time availability tracking
4. Automated payment system
5. Ticket generation and validation

Non-Functional Requirements

1. High availability
2. Low latency for spot assignment
3. Scalable to multiple locations
4. Secure payment processing

Class Diagram

ParkingLot
├── floors: List<Floor>
├── entrances: List<Entrance>
├── exits: List<Exit>
└── paymentProcessor: PaymentProcessor

Floor
├── spots: List<ParkingSpot>
└── availableSpots: Map<SpotType, Integer>

ParkingSpot (Abstract)
├── CompactSpot
├── LargeSpot
└── HandicappedSpot

Vehicle (Abstract)
├── Car
├── Motorcycle
└── Truck

Ticket
├── ticketId: String
├── vehicle: Vehicle
├── spot: ParkingSpot
├── entryTime: DateTime
└── exitTime: DateTime

Implementation

Core Classes

public enum VehicleType {
    CAR, MOTORCYCLE, TRUCK
}

public enum SpotType {
    COMPACT, LARGE, HANDICAPPED
}

public abstract class Vehicle {
    private String licensePlate;
    private VehicleType type;

    public abstract boolean canFitInSpot(ParkingSpot spot);
}

public class Car extends Vehicle {
    public Car(String licensePlate) {
        super(licensePlate, VehicleType.CAR);
    }

    @Override
    public boolean canFitInSpot(ParkingSpot spot) {
        return spot.getType() == SpotType.COMPACT ||
               spot.getType() == SpotType.LARGE;
    }
}

public abstract class ParkingSpot {
    private String spotId;
    private SpotType type;
    private boolean isAvailable;
    private Vehicle currentVehicle;

    public boolean park(Vehicle vehicle) {
        if (!isAvailable || !vehicle.canFitInSpot(this)) {
            return false;
        }
        this.currentVehicle = vehicle;
        this.isAvailable = false;
        return true;
    }

    public void removeVehicle() {
        this.currentVehicle = null;
        this.isAvailable = true;
    }
}

public class ParkingLot {
    private static ParkingLot instance;
    private List<Floor> floors;
    private Map<String, Ticket> activeTickets;

    private ParkingLot() {
        floors = new ArrayList<>();
        activeTickets = new HashMap<>();
    }

    public static synchronized ParkingLot getInstance() {
        if (instance == null) {
            instance = new ParkingLot();
        }
        return instance;
    }

    public Ticket issueTicket(Vehicle vehicle) {
        ParkingSpot spot = findAvailableSpot(vehicle);
        if (spot == null) {
            throw new NoAvailableSpotException();
        }

        spot.park(vehicle);
        Ticket ticket = new Ticket(vehicle, spot);
        activeTickets.put(ticket.getId(), ticket);
        return ticket;
    }

    private ParkingSpot findAvailableSpot(Vehicle vehicle) {
        for (Floor floor : floors) {
            ParkingSpot spot = floor.findAvailableSpot(vehicle);
            if (spot != null) {
                return spot;
            }
        }
        return null;
    }

    public double calculateFee(Ticket ticket) {
        long hours = ticket.getDurationInHours();
        return hours * 5.0; // $5 per hour
    }
}

Design Patterns Used

1. Singleton Pattern

• ParkingLot uses Singleton to ensure single instance

2. Factory Pattern

• VehicleFactory to create different vehicle types

3. Strategy Pattern

• Different pricing strategies (hourly, daily, monthly)

4. Observer Pattern

• Notify when spots become available

Interview Questions

Q1: How would you handle peak hours?

Answer:

• Implement reservation system
• Dynamic pricing during peak hours
• Queue management for waiting vehicles
• Real-time availability updates

Q2: How to scale to multiple locations?

Answer:

• Separate database per location
• Central management system
• Location-based routing
• Distributed caching (Redis)

Q3: How to handle payment failures?

Answer:

• Retry mechanism with exponential backoff
• Multiple payment methods
• Grace period for payment
• Manual payment option at exit

Optimization Strategies

1. Caching: Cache available spots count per floor
2. Indexing: Index on vehicle license plate and ticket ID
3. Load Balancing: Distribute entry/exit processing
4. Async Processing: Process payments asynchronously

Conclusion

This parking lot design demonstrates:

• Object-oriented design principles
• Design pattern application
• Scalability considerations
• Real-world problem solving

Key takeaways:

• Use appropriate design patterns
• Consider edge cases
• Plan for scalability
• Handle failures gracefully
